Crossmember Delete Front Bumper – 2012–2015 Toyota Tacoma

Maximum Clearance, Minimum Weight

The Crossmember Delete Front Bumper for the 2012–2015 Toyota Tacoma is engineered for serious off-road performance, combining maximum clearance and durability with a lightweight design. Built from 3/16” A36 steel with 1 ¾” × .120 DOM tubing and 1 ½” × .120 side support tubes, this rigid one-piece bumper weighs only 69 lbs while delivering strength you can trust. A laminated D-ring plate design ensures safe and secure recovery points on the trail.

Optional Replacement Crossmember

For added strength, a heavy-duty replacement crossmember is available. It bolts directly between the frame rails to provide a solid mounting base for both the skid plate and bumper.

Lighting Versatility

• Side-wing light mounts included (fit Baja Designs Squadron, S2, or similar-sized pods)
• Optional 7” light bar mount (sold separately) for even more lighting options

High-Clearance Engine Skid Plate

• Built from 3/16” steel with 8 mounting points (industry standard is 6)
• Flush-mounted access panels allow quick, easy oil changes
• Stainless CNC-machined washers protect panel hardware for long-term durability
• Works with Swaybars without spacers/drop brackets

Frame Reinforcement Included

• 3/16” weld-on frame reinforcements add strength and extend chassis life
• Designed to handle aggressive off-road abuse and long-term use

Specs

• Weight: 69 lbs
• Materials: 3/16" A36 steel plate main shell, 1/4" aluminum skid plate, .120-wall DOM tubing (1 3/4" and 1 1/2")
• Crossmember: Optional heavy-duty replacement available (bolts between frame rails)
• Recovery Points: Laminated plate D-ring design
• Lighting: Side-wing mounts fit Baja Designs Squadron, S2, and similar pods; optional 7" light bar mount available separately
• Skid Plate: 3/16" high-clearance steel skid with 8 mounting points, flush-mounted access panels, and stainless CNC-machined hardware
• Frame Reinforcements: 3/16" weld-on plates included
• Winch Mount: Compatible with ZEON and EVO series, Superwinch, and Carbon Off-Road (others may require modification)
• Finish: Ships raw
• Lead Time: 4-5 weeks (bull bars add 1-3 weeks)
